Sale
- Sku: g6505
- Vendor: Balboa Water Group
Balboa BP7 5.5kW Spa Control Pack With TP500
$849.00
$699.00
Shipping calculated at checkout.
In stock!
Estimated Shipping Widget will be displayed here!
Product Specifications
| Product Name | G6505 Balboa® Topside TP500 Control with BP7 and 5.5kW Heater |
|---|---|
| Voltage | 230V - 3 Wire, 230V - 4 Wire |
| Pump Capacity | Operates 1 or 2 Pumps with TP500 Topside |
| Programmable Options | 32 Configurable Settings |
| Heater Power | 5.5kW |
Bundle Kit Includes
- Control Box G4361
- Topside Control Panel 57238 with Overlay 17183
- Topside Adapter Plate 15380
- Light Cord 25098
- Pumps and Blower Cords (Sold Separately)
- Light Cord Only (No Reflector)
Accessories
WiFi Control:
- 50350 — WiFi Control, Balboa, Interface Module
Fuses:
- SC-30 — 30A, 115V, Time Delayed (30136) for F6, F8, and Expander Board
- 26307 — 2A, 3/4" Glass Fuse for F4
- 26905 — 0.5A, 3/4" Glass Fuse for F3
- 26904 — 10A, 250V Blower Fuse (5x20) for F2 and F7
- 26976 — 3.15A, 250V, Slow-Blo Fuse for F5
Replacement Options
The G6505 Balboa® TP500 Control System can replace the following models:
389173, VS300, VS500Z, VS501Z, VS501SZ, VS503SZ, VS504SZ, VS510SZ, VS510DZ, VS511Z, VS511SZ, VS513Z, VS514SZ, VS515SZ, VS515Z, VS520Z, VS520SZ, VS520DZ, VS525Z
